Shop NowPVC pipe is the cheapest building set for a backyard. You cut it with a hacksaw or a pipe cutter, snap it together with elbows and tees, and glue the joints you want to keep.
Most projects use 3/4 inch or 1 inch pipe and take under an hour once the pipe is cut. Dry-fit the parts first, and glue only the joints that carry weight.
Adults should do the cutting and the cement. The Oatey cement safety data sheet calls it a highly flammable liquid and says to use it only outdoors or in a well-ventilated area. Safe Kids Worldwide says small children can drown in as little as one inch of water.
Answer 4 quick questions and get matched to the exact fix for your yard — drainage, budget, layout, or something else entirely.
Take the Free QuizThis guide gives 14 projects, each with sizes, parts, steps, a watch-out and our verdict. It also covers tools, cement safety, water play rules, cost tiers and common mistakes.
What Is Wrong With a Plain List of Pipe Projects for Kids?
Most lists show 35 photos and link out to old blog posts. Many of those links are dead now, and a few lead to unrelated sites. A list like that can’t tell you what to buy.
We opened every tutorial we could and kept the ones that still load. Each project below has sizes and parts, taken from the source, and a note on what to watch. We left out slingshots and bows, because projectile toys are the biggest eye risk on the old list.
What Tools and Pipe Do You Need?
Pick one pipe size per project, and buy fittings to match. Many of these builds use 3/4 inch pipe, and a few use 1 inch or 2 inch.
| Item | Use it for | Notes |
|---|---|---|
| 3/4 inch PVC pipe | Frames, water toys, canopies | The most common size here |
| 1 inch PVC pipe | Ladder golf, foosball | Sturdier for games |
| Elbows, tees, crosses, caps | Corners and joints | Buy a few extra |
| Hacksaw or PVC cutter | Cutting pipe | Adult job only |
| PVC cement | Permanent joints | Use outdoors |
| Sandpaper | Smoothing cut edges | Rough edges scratch hands |
| Spray paint | Color and protection | Use light coats |
One reader of the sand table post found the frame sagged and swayed until the joints were glued. The author agreed that glue “made a huge difference.”
Most yard problems trace back to one specific, fixable cause. Find yours in 4 quick questions.
Take the Free QuizOur rule: dry-fit every piece before you glue anything. Cement sets fast, and you can’t undo a bad joint.
Game Projects
1. Ladder Golf
Kelly Leigh Creates builds this from 20 feet of 1 inch pipe, 2 elbows and 6 tees. Cut 3 pieces at 2 feet, 6 at 18 inches and 4 at 1 foot. Each throwing piece is two golf balls joined by about 18 inches of paracord, and a set makes eight.
Two teams of two score 3 points for the top rung, 2 for the middle and 1 for the bottom. If both teams hook the same rung, it cancels. A reader suggested weighing the base with sand or concrete.
Pair with: a patch of flat lawn.
But watch out: golf balls need holes drilled through them. An adult should do that, and singe the cord ends so they don’t fray.
Our take: our top pick for mixed ages. You can leave the pieces unglued, so the set stores flat.
Get the tutorial at Kelly Leigh Creates.
A ratchet cutter for 3/4 and 1 inch pipe. An adult should make every cut, then sand the edges smooth.
Shop NowThis post contains affiliate links. We may earn a commission on qualifying purchases at no extra cost to you.

2. Human Foosball
Kid Friendly Things To Do builds the court from 1 inch pipe. You need seven 10-foot lengths, eight elbows and eight buckets. Cut eight legs at 38 inches, and fill each bucket with Quikrete to hold a leg.
Set two buckets 10 feet apart and fit a 10-foot pipe into the elbows to make a rod. Four rods make the field. If pipes pop out during play, wrap them with duct tape.
The average homeowner spends $616/year on yard fixes that don't address the real problem. Find out what yours actually is — before you spend another dollar.
Take the Free QuizPair with: matching team shirts.
Watch out: wet cement is harsh on skin. Wear gloves while you mix it, and let the buckets cure fully.
Our take: the biggest project in this group, and the best for a birthday party.
Get the tutorial at Kid Friendly Things To Do.

3. A PVC Field Goal Post
Play Party Plan uses 3/4 inch pipe. Cut four 12-inch pieces and six 6-inch pieces. Join them with four elbows and tees into a goal post shape, and spray the post yellow and the feet black.
The set makes two posts, and takes 30 minutes in total with 10 minutes of hands-on work. The hardware store can cut the pipe for you.
Pair with: a foam football.
But watch out: loose fittings. One reader found the pipe too loose in the connectors, so test the fit before you build.
Our take: the quickest build on this list. Paint in thin coats to avoid drips.
Get the tutorial at Play Party Plan.

4. A Spinning Target
Frugal Fun 4 Boys hangs spinning targets from a dowel on a PVC pipe frame. Trace a plastic cup onto cardboard, decorate the circles and glue two to each craft stick. Slide taped straws over the dowel so the targets spin, and add a penny for weight.
Tape the dowel to the top of the frame. The post says targets won’t hang right without the penny.
Pair with: soft foam balls.
Watch out: keep permanent markers away from small children. Hot glue also did not hold the pennies, so use duct tape.
Our take: a good target for beanbags and foam balls. Skip hard balls.
Get the tutorial at Frugal Fun 4 Boys.

Music and Sensory Projects
5. A PVC Pipe Xylophone
Frugal Fun 4 Boys builds an eight-note instrument, mostly from 2 inch pipe. The pipes run from 26.75 to 35 inches long, and pitch depends mainly on length. Short pipes sound higher, and wider pipe sounds louder.
Cut each pipe slightly long, then trim a little at a time to tune it. Strike the pipes with a mallet made from a fly swatter covered in craft foam. Attach the pipes to a frame with metal brackets.
Pair with: a free phone tuner app.
But watch out: a too-short cut raises the note for good. The author warns that a pipe on the ground changes its pitch, so use a stand.
Our take: a clever project for older kids. Tuning is half of the fun.
Get the tutorial at Frugal Fun 4 Boys.

6. A Sand and Water Table
Frugal Fun 4 Boys uses 3/4 inch pipe, four 10-foot lengths and 14 tees. Two under-bed tubs, each 35.5 by 16.5 by 6.5 inches, sit in the frame. The author spent about $70 in the first version, and $30 of that was the tubs.
Glue all joints except the funnel pipes, which stay removable. Keep sand or water only a couple of inches deep to limit the weight. Turn the table upside down to drain it.
Pair with: scoops, funnels and cups.
Watch out: water enters the legs. Drill drain holes in the leg caps. Put the table in the shade and cover the sand tub when you finish.
Our take: our favorite for toddlers. Follow the water rules below, because even a shallow tub is a risk for the youngest.
Get the tutorial at Frugal Fun 4 Boys.

7. A Funnels and Tubes Sensory Table
Frugal Fun 4 Boys builds a small PVC frame inside an under-bed tub. Funnels held by cross fittings sit on top, with the ends cut off so beans fit through. Duct tape holds the funnels, since they wobble after cutting.
Fill the tub with beans, and add egg cartons, spoons and cups. The author ruled that kids who just make a mess lose their turn.
Pair with: a sheet underneath for easy cleanup.
But watch out: small beans are a choking risk for toddlers. The post doesn’t mention it, so make this one for older kids and supervise.
Our take: an indoor project for a rainy day. Dyed beans can rub off on fingers.
Get the tutorial at Frugal Fun 4 Boys.

Water Play Projects
8. A Kiddie Car Wash
Mom Endeavors builds it from 3/4 inch pipe. You need eight 10-foot lengths, 11 tees, 7 elbows, 4 crosses and 4 caps. The author says the sprinkler build costs under $25.
Drill holes with a 1/16 inch bit, about 4 or 5 per 3-foot piece. Start with fewer holes and add more, because strong pressure blew the structure apart. Hang pool noodles and sponges for the wash.
Pair with: ride-on toys and a bucket of soapy water.
But watch out: pressure. A commenter suggests schedule 40 pipe for strength. Turn the water on slowly.
Our take: the best summer project on the list. The frame comes apart for storage, so label each piece.
Get the tutorial at Mom Endeavors.

9. Water Blasters
Mom Endeavors uses 3/4 inch pipe, three 10-foot lengths, five tees and three elbows. Each station has a ball valve and a pool-noodle blaster, with tubing threaded through half a noodle. The author says you can build it in under an hour.
Open the water slowly. The post warns that turning it up to full blast too fast “will pop apart the pipes.”
Pair with: a hose with a shutoff.
Watch out: water jets can hurt eyes. Prevent Blindness Florida lists toys that shoot water among the eye risks. Set the stations to aim at targets, not at faces.
Our take: fun for a hot day, but only with rules. Skip it for toddlers.
Get the tutorial at Mom Endeavors.

Shelter and Storage Projects
10. A Covered Car Garage
Mom Endeavors builds a frame from five 10-foot lengths of 3/4 inch pipe with elbows and tees. Anchor it with curved wire stakes, and attach a corrugated roof panel with screws. Hang drop cloth curtains from clip rings.
You will need a saw, a drill and scissors. The roof needs two or three screws along the sides and back.
Pair with: a sign above the door.
But watch out: wind. The author says one storm partly blew the structure over, so stake it well.
Our take: a smart way to organize ride-on toys. For more backyard ideas, see our DIY backyard ideas for kids.
Get the tutorial at Mom Endeavors.

11. A Sandbox Canopy
My Happy Crazy Life makes a fabric canopy over an 8 foot sandbox with 3 yards of outdoor fabric. The first try used flexible PVC, but it bent under the fabric weight. The author switched to electrical conduit for the arches and joined it with compression connectors.
Sink the legs into the sand and screw a strap onto each corner board. In high wind, push the canopy to the ground.
Pair with: a sandbox cover.
Watch out: arches that are too short. The first set was too short for kids to stand under.
Our take: a useful lesson in picking the right material. Rigid pipe or conduit beats flexible pipe for load.
Get the tutorial at My Happy Crazy Life.

12. A Pipe-Frame Play Fort
Build a cube frame from 3/4 inch pipe, with corner fittings at each joint. Drape bed sheets or a tarp over the top and clip them with spring clamps. Leave the joints unglued so the fort folds flat.
Pair with: a rug and floor cushions.
But watch out: sheets can slip off a slick frame. Use clamps or clothespins.
Our take: a fun indoor build for a rainy afternoon. We could not open the original fort tutorial, so this is our own plan, with no fixed measurements.

13. A Pipe Periscope
Build a periscope from two short pipes and a pair of small mirrors. Join the pipes with an elbow so the line of sight turns. Place the mirrors inside the pipe ends, angled so they face each other.
Pair with: a spy costume.
Watch out: mirrors have sharp edges. Use plastic acrylic mirrors for kids, and cover the edges with tape.
Our take: a quick project for the youngest. The original tutorial wouldn’t load, so we give the idea and no fixed sizes.

14. A Pipe and Wood Race Track
Make a ramp from pipe halves or wood strips, and prop it on pipe legs. Kids race small cars down the ramp. Our guide to DIY race car tracks for kids has more plans for tracks.
Pair with: a chalk finish line.
But watch out: loose fittings. Glue the legs, so the ramp doesn’t fall during a race.
Our take: a calm project for a younger child. It also teaches how slope changes speed.

How Do You Use PVC Cement Safely?
Cement is for adults only. The Oatey sheet lists the all-purpose cement as a highly flammable liquid and vapor. It says to keep it away from heat, sparks and open flames, and to use it only outdoors or in a well-ventilated area.
The same sheet says to wear protective gloves and eye protection, and to store the container in a cool place, tightly closed and locked up. Don’t eat, drink or smoke while you work.
Our rule: do the gluing before the kids come out to play, and let the joints cure before they handle the parts.
How Do You Keep Water Play Safe?
Water play needs an adult. Small children can drown in as little as one inch of water. An adult should stay within arm’s reach of any infant or toddler in or near water.
When several adults are present, name one a Water Watcher for a set period, such as 15 minutes. Empty tubs and tables when play ends. Drowning is the leading cause of injury-related death among children ages 1 to 4.
Our rule: never leave a water table full and unattended, even for a minute.

What Other Safety Rules Apply?
Adults do the cutting. Sand or sand cut edges before kids touch the pipe. Check each build for loose parts every time you use it.
Skip slingshots, bows and launchers. The same group says toys that shoot pellets, foam darts, arrows or water can cause serious eye damage. If you build a water toy, set clear rules about aiming.
Keep small parts, beans and cut ends away from toddlers. Store pipe and fittings out of reach.
What Will It Cost, and How Long Will It Take?
Prices vary by store and region, so use these tiers.
| Tier | What it covers | Typical time |
|---|---|---|
| Free to cheap | Field goal post, spinning target, play fort, periscope | 30 minutes to an hour |
| One afternoon | Ladder golf, xylophone, car wash, water blasters | 2 to 4 hours |
| Bigger project | Human foosball, sand and water table, car garage | A weekend |
Start with the cheap tier. For more wood and pipe ideas, see our fun wood projects for kids.
Common Mistakes to Avoid
Skipping the glue on a frame that holds weight. Unglued tables sag and sway.
Cutting a pipe too short. Cut long and trim.
Turning the water on full blast. Pressure can pop the pipes apart.
Using cement indoors. Work outside, or in a well-ventilated area.
Leaving water in a tub. Empty it when play ends.
FAQ
What can kids make with PVC pipe? Games, water toys, a xylophone, a play fort and a sand and water table are all easy builds.
What size PVC pipe is best for kids’ projects? Most use 3/4 inch or 1 inch pipe. Pick one size per project.
Do I need to glue PVC for kids’ projects? Glue frames that hold weight. Leave play forts and games unglued so they fold flat.
Is PVC cement safe for kids to use? No. Adults should use it outdoors, and kids should stay away until it cures.
How do I keep kids safe around DIY water toys? Supervise closely, empty tubs after play and never aim at faces.
